Description Specification OcuSync Operating frequency range* : 5.150-5.250 GHz; 5.725-5.850 GHz Transmitter power (EIRP) 2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC) 5.1 GHz: <23 dBm (FCC/CE) 5.8 GHz: <33 dBm (FCC), <14 dBm (CE), <30 dBm (SRRC) Wi-Fi 802.11 a/b/g/n/ac/ax Operating frequency range*: 2.4000-2.4835 GHz; 5.150-5.250 GHz; 5.725-5.850 GHz Transmitter power (EIRP) 2.4 GHz: <26 dBm (FCC), <20 dBm (CE/SRRC/MIC) 5.1 GHz: <26 dBm (FCC), <23 dBm (CE/SRRC/MIC) 5.8 GHz ＜26 dBm (FCC/SRRC), ＜14 dBm (CE) Bluetooth Bluetooth 5.2 Operating frequency: 2.4000-2.4835 GHz Transmitter power (EIRP): <10 dBm Model: TKPL2 Battery type: Lithium-ion (6500 mAh, 7.2 V) Chemistry: LiNiCoAlO2 USB-C chargers with a maximum rated power of 100 W are recommended Rated power: 12.5 W GNSS: GPS Galileo BeiDou Video output port: HDMI Type A Operating temperature: -20° to 50°C Storage temperature Within one month: -30° to 45°C One to three months: -30° to 35°C Three months to one year: -30° to 30°C Charging temperature: 5° to 40°C * The permissible operating frequency varies by country and region. Please refer to local laws and regulations for more information.
