For Bulk requirement, Kindly click on enquiry now button Product Details: Product Description Brand Autonics Model No. PA-12 Type Selectable NPN/PNP Power supply Selectable 110-120VAC ~50/60Hz Power Consumption Approx.4VA Power supply for sensor 12VDC±10% 50mA Control Output • Relay contact output(Contact capacity:250VAC~3A, 30VDC~3A resistance load, contact arrangement1a1b) • Life expectancy Mechanical: Min 10,000,000 operations Electrical: Min 1,00,000 operations Input Signal • NPN Short-circuit impedance: Max 1kΩ Open-circuit impedance: Min 100kΩ • PNP High Level: 7-12VDC Low Level: 0-5VDC Input Resistance 10kΩ Response Time Input : Min.0.2ms output: Min. 10ms Environment Ambient temp. -10 to 50ºC Ambient humi. 35 to 85%RH Unit Weight Approx. 269g Above specifications mentioned are for quick reference only. Actual technical details has to be obtained from below catalog.
